Product Details:

Place of Origin: China
Certification: ISO 9001:2008, CE, CCC, QS
Model Number: OBBL2-180L

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: nigotiation
Packaging Details: Plastic film + Plywood case
Delivery Time: 20 days
Supply Ability: 100 units per month
Get Best Price Contact Now

Detail Information

Compressor Brand: , Carlyle, Danfoss, Copeland, Bock, Hanbell, Fusheng, Etc. Cooling Type: Water Cooled
Refrigerant: R404a, R22 Voltage: 380V/3P/50Hz, 220V/1P/60Hz
Use: Cold Room, Blast Freezer, Cold Chain Logistic, Pharacy, Refrigeration Evaporating Temperature: 10~-15℃, -15~-35℃, -30~-50℃
Condensing Temperature: 35℃ Compressor Type: Screw Type
High Light:

copeland condensing unit

,

air cooled condensing units

Product Description

Characteristics:

1. Components such as compressor, reservoir, gas-liquid separator, oil separator, economizer, intake manifold, fluid supply manifold, electrical control equipment are all centralized, making sure every inch of the space is fully used.
2. The unit has a compact structure, the space saved during assembly can provide more space for commercial use, benefiting the end user with extra profit.



Wide Range of Options

Compressor Unit

Refrigeration Capacity

Evaporating temperature

Piston type single-stage parallel unit

20HP~350HP

7.5℃~-45℃

Piston type Two-stage parallel unit

16HP~180HP

-25℃~-65℃

Screw type single stage parallel unit

80HP~600HP

5℃~-45℃

Screw type double-stage parallel unit

100HP~600HP

-30℃~-65℃



Feature

1. screw compressor

2. With full range, air cooled & water cooled.

3. Multi stage energy-controlling system

4. All the accessories are world famous brand, which with reliable quality.

5. Testing condition: ambient temperature 35oc, condensing temperature 50oc

6. Wide application, suitable for different refrigerant.

7. Optional configuration is acceptable.

8. CE approved.





Ice Making Machine Cold Storage Unit Cooler Unit Multi Stage Energy Controlling System 0

Ice Making Machine Cold Storage Unit Cooler Unit Multi Stage Energy Controlling System 1Ice Making Machine Cold Storage Unit Cooler Unit Multi Stage Energy Controlling System 2Ice Making Machine Cold Storage Unit Cooler Unit Multi Stage Energy Controlling System 3
