Adopted to multiple refrigerant R404a, R507, R407C, R22.
We produce our compressor racks with world famous components and the world lastest technology. Each
compressor rack is standardly equipped with phase loss protection, reverse phase order protection, over
voltage/lack voltage protection, oil pressure protection, high/low pressure protection, motor over load protection,
etc. This would enable our compressor racks to avoid frequently startup/off and provide a stable and reliable
performance to end user.
We have hight effciency oil separation system, when the unit is on, there's no need to use lubracation, the
standard oil temperature heater , oil temperature controller and oil level controller can make sure a perfect
Each compressor rack is equipped with PLC controller, it can automatically decide how many compressors to be
used according to the actual need, even the running time between all compressors, so that the electricity can be
saved, also the compressors can have 30% more use life compared with single compressor condensing unit.
Our compressor racks are widely used in fruit fresh keeping, vegetable storage and production, seed storage,
etc. We hope to work with more and more refrigeration contractor to provide the best refrigeration solution to the
Stable & Reliable Performance
- The units are equipped with world famous brand high quality compressor and components, following the
- latest design, the perfect combination provides a safe and reliable system.
- The unit comes standard with a controller that can effectively avoid turning on/off the motor frequently as
- well as safety protection modules including the following: Phase loss protector, Inverted sequence,
- overvoltage protector, undervoltage protector, oil pressure, high pressure, low pressure, motor overload.
- High efficiency oil separating system. When power is on, there is no need to add lubricating oil, the
- standard provided oil heater (for screw unit), oil temperature controller (for screw unit) and oil level
- switch (for screw unit), etc. can protect the function.
- The PLC controller is a standard provided component. It can automatically decide the compressor
- quantity to be used based on actual need of refrigerant capacity, average the running time between
- each compressor, save the power. All of these will guarantee an over 30% longer usage than single
- compressor condensing unit.
- It has a unique low environment condensing pressure monitor system which guarantees a stable
- functioning when there is a low ambient temperature, lack of oil feeding or oil flow warnin
- High efficiency gas liquid separator is used, with a unique pipeline design, it can effectively minimize the
- possibility of liquid strike.
- The “Pressure Vessel Certificate” approved reservoir is provided as well as the safety relief valve.
- Fault isolation device is served so that when a certain compressor breaks down, the rest of the unit can
- keep running appropriately, making sure that client has enough time for repair and replacement.
High efficiency & energy saving
- Because of a huge demand difference between seasons for refrigerating capacity, the unit must have a
- high level control for capacity, so that the unit can keep running under high efficiency mode. The average
- parallel unit efficiency, according to different refrigeration system is 30% higher than single compressor unit.
- Using multiple compressor parallel units can provide a multiple energy level control, the refrigeration output
- can be dynamically allocated more smoothly according to actual situation.
- With high efficiency oil separator, only a small amount of lubricating oil enters the system, this largely brings
- up the heat exchanging efficiency.
- The PLC controller monitors running compressors quantity, it maintains a maximum use rate even when
- only parts of the compressors are functioning.
- PLC controller can be set with the best running curve (maximum & minimum power comsuption), to same
- as much electricity as possible.
- With “modularized design” the risk during construction can be largely reduced, construction period can be
- shortened, improve the product quality controllability.
Compact & Nimble Structure
- Components such as compressor, reservoir, gas-liquid separator, oil separator, economizer, intake
- manifold, fluid supply manifold, electrical control equipment are all centralized, making sure every inch of
- the space is fully used.
- The unit has a compact structure, the space saved during assembly can provide more space for
- commercial use, benefiting the end user with extra profit.
Easy operation & convenience
- With PLC safety auto control, client can program with touch screen, the graphical control interface can
- intently show the running status, recording data, parameter settings and false alarming, easy for operation.
- The reserved remote communication interface can help customer to monitor remotely.
- Thanks to the print output interface, customer can print the running history data of the unit and the system.
||Meat, egg, etc.
||Meat, poultry, rabbit, frozen egg, vegetable, etc.
||Fish, shrimp, etc.
||Chilled product cold storage
||Cooled meat, poultry, etc.
||Apple, pear, etc.
Chinese cabbiage, Garlic sprouts, onion,
spinach, parsley, carrots, cabbage, celery,
||Potatoes, oranges, persimmons, etc.
Bell pepper, beans, cucumber, tomato,
||Frozen product cold storage
Frozen meat, poultry, rabbits and
frozen eggs, frozen vegetables,
popsicles and other
||Frozen fish and shrimps
