• Compressor Rack For Hight Temperature Cold Storage With  Piston Compressors, R404a
  • Compressor Rack For Hight Temperature Cold Storage With  Piston Compressors, R404a
Compressor Rack For Hight Temperature Cold Storage With  Piston Compressors, R404a

Compressor Rack For Hight Temperature Cold Storage With Piston Compressors, R404a

Product Details:

Place of Origin: Jinan, China
Brand Name: Ourfuture
Certification: CE, 3C, ISO9001:2008
Model Number: OBBL2-20M

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 5000~8000 per unit
Packaging Details: Plywood case with steel pallet
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 50 units per month
Get Best Price Contact Now

Detail Information

Voltage: 380V/3/50Hz Refrigerant: R404a
Compressor Type: Reciprocating Type Compressor Control Type: PLC
High Light:

Reciprocating Type Compressor Rack

,

R404a Compressor Rack

,

PLC Compressor Rack

Product Description

Compressor Rack For Hight Temperature Cold Storage With Piston Compressors, R404a

Rack model(OBBH) 2-20M
Refrigerant R404A
Voltage 380V/50HZ
Evaporating temperature 10℃~-15℃
Condensing temperature 35℃
Condenser type Evaporative condenser
Economizer With
Compressor Type Piston Type
Model 4VES10
Qty 2
Refrigerating capacity & power Evap. Temp.0℃ Qo(W) 62800
Pe(KW) 15.14
Evap. Temp.-5℃ Qo(W) 51600
Pe(KW) 14.34
Evap. Temp.-10℃ Qo(W) 42000
Pe(KW) 13.36
Connector Air inlet(mm) 45
Liquid outlet(mm) 19
Air outlet(mm) 28
Liquid inlet(mm) 22
Overall dimension L(mm) 1442
W(mm) 1100
H(mm) 1800



Compressor rack product range
Single compressor condensing unit
  Air cooled condenser Water cooled condenser Evaporative cooled condenser
Scroll type compressor
Piston type compressor
(One stage/Two stage)
Screw type compressor
(One stage/Two stage)
Parallel compressor racks
Evap. Temp. -14~10℃ -15~-35℃ -36~-60℃
Scroll type compressor
Piston type compressor
(One stage/Two stage)
Screw type compressor
(One stage/Two stage)
Available refrigeration system Freon Direct expansion refrigeration system
Freon Barrel pump/surge drum refrigeration system
Brine refrigeration system (Freon/Glycol/Calcium chloride)
CO2 as secondary refrigerant refrigeration system
CO2 Cascade system
Other products & service
1. Refrigeration system design, selection and quotation.
2. Unit cooler, plate heat exchanger, water cooling condenser, evaporative condenser, CA storage equipment, etc.
3. PLC auto control customized programming, APP remote control.
4. Equipment supply including refrigeration, insulation & auxilary materials.
5. Global installation service.
Application
1. Fruit & vegetable precooling, storage, controlled atmosphere storage(CA storage) and freeze drying, etc.
2. Poultry & meat exclusion, precooling, quick freezing and freezing storage, etc.
3. Sea food (Fish & shrimp, etc) quick freezing, storage and -60℃ deep freezing storage.
4. Chemical refrigeration.
5. Water chiller for workshop air conditioning, poultry processing, etc.
6. Heat pump that producing hot water for poultry feather removing, etc.
What we don't do
1. We don't do Ammonia related refrigeration system.
2. Commercial air conditioner.
3. Air compressor.
Socia media & contact info
1. Facebook: www.facebook.com/compressorracks
2. Blogger: compressorracks.blogspot.com
